Powerful power, precise control
Equipped with a high-performance Kubota engine, it provides powerful power output, and is equipped with an intelligent hydraulic system, which responds quickly and operates smoothly, easily coping with high-intensity work requirements.
Supports quick switching of 20+ attachments such as forklift arms, sweepers, and drills, and one machine can meet the needs of multiple scenarios such as material handling, land leveling, and snow removal.
| Performance | Operating weight（kg） | 1330 | ||||||||||
| Rated load（kg） | 400 | |||||||||||
| Bucket capacity（m³) | 0.2 | |||||||||||
| Max Speed（km/h） | 5.6 | |||||||||||
| Max traction（kN） | ≥ 12 | |||||||||||
| Max breakout（kN） | ≥ 7 | |||||||||||
| Lifting time of boom（s） | 7 | |||||||||||
| Engine | Manufacturer | Kubota | ||||||||||
| Model | D1105 | |||||||||||
| Rated power（kW/rpm） | 18.2/3000 | |||||||||||
| Engine displacement（L） | 1.123 | |||||||||||
| Emission Standard | EU2/EPA4 | |||||||||||
| Dimension | Overall operating height（mm） | 2800 | ||||||||||
| Height to bucket hinge pin（mm） | 2159 | |||||||||||
| Height to top of cab（mm） | 1685 | |||||||||||
| Height to bottom of level bucket（mm） | 2831 | |||||||||||
| Without bucket length（mm） | 2165 | |||||||||||
| Overall length with bucket（mm） | 2831 | |||||||||||
| Dumping angle at maximum height(°) | 30 | |||||||||||
| Dumping height（mm） | 1685 | |||||||||||
| Dumping reach（mm） | 611 | |||||||||||
| Rollback of bucket on ground(°) | 30 | |||||||||||
| Rollback of bucket at full height(°) | 103 | |||||||||||
| Wheelbase（mm） | 1149 | |||||||||||
| Ground clearance（mm） | 258 | |||||||||||
| Angle of departure(°) | 29 | |||||||||||
| Front turning radius without bucket（mm） | 970 | |||||||||||
| Front tuning radius（mm） | 1496 | |||||||||||
| Rear tuning radius（mm） | 1496 | |||||||||||
| Rear axle to bumper（mm） | 910 | |||||||||||
| Tread width（mm） | 826 | |||||||||||
| Width (mm) | 1006 | |||||||||||
| Bucket width（mm） | 1166 | |||||||||||
